Graoch Multistage Booster Pumps
Graoch pumps is compact multistage ss booster pumps used for domestic and light comertcial use. Pumps Is Designed for Long Troble Free Silent Operation
-
Silent operation,compact design and high reliable
-
Wide perfomance range
-
liquied temp from 20C TO 90C
-
In Built thermal overload protection
-
F Class insulation
Application
Pressure Boosting for domestic building and comerical building
Water transfer from U.G to O.H tank
Comerical RO Plant
| Model | Q(M3/H) | 1 | 1.5 | 2 | 3 | 3 | 3.5 | 4 | ||
|---|---|---|---|---|---|---|---|---|---|---|
| KW | HP | Q(L/Min) | 16.7 | 25 | 33.3 | 50 | 50 | 58.3 | 66.6 | |
| GMS 2-20 | 0.3 | 0.4 | H | 16.2 | 15 | 14 | 10.6 | 10.6 | 8.8 | 3.2 |
| GMS 2-30 | 0.45 | 0.6 | 24.3 | 23.8 | 21.3 | 16.1 | 16.1 | 12.5 | 7.5 | |
| GMS 2-40 | 0.55 | 0.75 | 34.1 | 33.2 | 30.7 | 22.9 | 22.9 | 18.4 | 13.4 | |
| GMS 2-50 | 0.75 | 0.1 | 42.1 | 39.5 | 35.9 | 25.7 | 25.7 | 22.6 | 17.6 |
| Model | Q(M3/H) | 1 | 2 | 3 | 4 | 5 | 6 | 7 | ||
|---|---|---|---|---|---|---|---|---|---|---|
| KW | HP | Q(L/Min) | 16.7 | 33.3 | 50 | 66.6 | 83.3 | 100 | 116.6 | |
| GMS 4-20 | 0.55 | 0.75 | H | 17.8 | 17.2 | 16.1 | 14.3 | 11.3 | 6.3 | 2.3 |
| GMS 4-30 | 0.55 | 0.75 | 26.7 | 26.4 | 24.6 | 22.1 | 16.3 | 13.5 | 7.3 | |
| GMS 4-40 | 0.75 | 1 | 36.1 | 35.2 | 32.9 | 22.9 | 24.7 | 18.6 | 15.2 | |
| GMS 4-50 | 1.1 | 1.5 | 45.7 | 43.6 | 40.5 | 37 | 31.8 | 21.8 | 18.2 | |
| GMS 4-60 | 1.5 | 2 | 53.6 | 52 | 47 | 42.5 | 35 | 26 | 22 |
